Approvals and Conformities
Boeing PN/Spec#
BMS 3-11P Type V, Grade B & C, Type IV, Class 1
Boeing M.D. PN/Spec#
DMS 2014H
SAE Spec#
AS1241C
Alternate PN#s
CMS-OL-103 C-34-1224C BAC.M.333C 1159SCH302J
Product Attributes
Country of Origin
United States
Size
55 Gallon
Shipping Weight
520 pounds
ECCN
EAR99
Color Family
Purple
Manufacturer P/N
HYJET IV-A PLUS
Schedule B Code
2710.19.3010
Pack Quantity
1
Ship Dimensions
23 x 23 x 35 inches
Size
55 Gallon Drum
Spec
BMS 3-11P Type V, Grade B & C, Type IV, Class 1
Color
Purple
Exxon HyJet IV-Aplus is a fire-resistant phosphate ester hydraulic fluid designed for use in commercial aircraft. It is the best-performing Type IV fluid and approaches to a great extent many of the performance capabilities of Type V fluids, including high temperature stability, fluid life, low density, and rust protection. It is superior to all other Type IV fluids in these respects. Exxon HyJet IV-A plus meets the specifications of all major aircraft manufacturers and SAE AS1241.
Features
| Features | Advantages and Potential Benefits |
|---|---|
| Best in high temperature stability among Type IV fluids | Longer fluid life. Lesser need to replace fluid due to degradation. Reduced hydraulic system maintenance costs |
| Lowest density Type IV fluid | Reduced weight of the hydraulic fluid carried by aircraft. Reduced aircraft fuel consumption, lower operating costs |
| Effective rust protection | Reduced the risk of equipment damage in the event of major water contamination |
| Excellent low temperature flow (viscosity) properties | Precise hydraulic system control and response even during extended range/polar flights. Longer equipment life |
| Excellent deposit control | Longer equipment life. Reduced maintenance costs |
| Excellent protection against electro-chemical corrosion (erosion) | Protection against servo valve and pump damage |
| Approved by all major aircraft manufacturers | Use as fleet lubricant by airline operators |
| Fully compatible with all approved phosphate ester hydraulic fluids | Flexibility in use by airline operators |
| Test Method | HyJet IV-A plus (1) | Limits | |
|---|---|---|---|
| Kinematic Viscosity, cSt | ASTM D 445 | ||
| at -53.9ºC (-65ºF) | 1320 | 2000 max | |
| at 37.8ºC (100ºF) | 10.6 | 10.0 -11.0 | |
| at 98.9ºC (210ºF) | 3.6 | 3.35 - 3.75 | |
| at 127.6ºC (260ºF) | 2.6 | 1.5 min | |
| Viscosity Index | ASTM D 2270 | 280 | |
| Shear Stability, % Viscosity Drop at 40ºC | ASTM D 5621 | 22 | |
| Pour Point, ºC (ºF) | ASTM D 97 | ‹-62 (-80) | -62 (-80) max |
| Specific gravity at 25ºC/25ºC (77ºF/77ºF) | ASTM D 4052 | 0.996 | 0.993 -1.005 |
| Density at 15.6ºC (60ºF), g/mL (lb/gal) | ASTM D 4052 | 0.999 (8.34) | |
| Acid Number, mg KOH/g | ASTM D 974 | 0.03 | 0.1 max |
| Water, Karl Fischer, mass % | ASTM D 6304 | 0.08 | 0.2 max |
| Flammability | |||
| Flash Point, ºC (ºF) | ASTM D 92 | 175 (347) | 160 (320) min |
| Fire Point, ºC (ºF) | ASTM D 92 | 189 (373) | 177 (350) min |
| Autoignition Point, ºC (ºF) | ASTM D 2155 | ›427 (800) | 400 (752) min |
| Foaming Tendency/Stability, mL foam/sec to collapse | ASTM D 892 | ||
| Sequence I | 20/18 | 250/100 max | |
| Sequence II | 20/5 | 150/50 max | |
| Sequence III | 23/13 | 450/250 max | |
| Particle count, NAS 1638 Class | Auto Counter | 4 | 7 max |
| Chemical Elements, ppm | |||
| Calcium | 102 | 120 max | |
| Potassium | 38 | 48 max | |
| Chlorine | 7 | 50 max | |
| Sodium | 1 | 15 max | |
| Sulfur | 220 | 350 max | |
| Four-Ball Wear, Scar diameter at 75ºC/600rpm/1hour, mm | Modified ASTM D 4172 | ||
| 4 kg | 0.22 | 0.45 max | |
| 10 kg | 0.33 | 0.50 max | |
| 40 kg | 0.73 | 0.55 – 0.85 | |
| Electrical Conductivity at 20ºC, microSiemens/cm | 1.4 | 0.5 min | |
| Bulk Modulus, Isothermal secant at 100ºF/3000 psi, psi | 210,000 | ||
| Thermal Conductivity at 40ºC, cal/sec/cm2/ºC (Btu/hr/ft2/ºF) | 33x10^-5 (0.0799) | ||
| Coefficient of thermal expansion, 25 to 100ºC, per ºC (per ºF) | 0.00086 (0.00048) | ||
| Specific heat capacity at 40 ºC, cal/g/ºC (same as Btu/lb/ºF) | 0.41 |
