Country of Origin
United States
Shipping Weight
0.05 pounds
Manufacturer P/N
MS20219-5
Schedule B Code
8487.90.0080
Groove Depth: 0.156 Inches Nominal Groove Width: 0.140 Inches Minimum And 0.150 Inches Maximum Outside Diameter: 2.620 Inches Minimum And 2.630 Inches Maximum Overall Length: 0.433 Inches Minimum And 0.438 Inches Maximum Bore Diameter: 0.625 Inches Nominal Bore Length: 0.433 Inches Minimum And 0.438 Inches Maximum Groove Radius: 0.047 Inches Minimum And 0.050 Inches Maximum Material And Location: Steel Hub Err-100 Err-100 Material And Location: Plastic, Phenolic Body Err-100 Err-100 Face Width: 0.300 Inches Minimum And 0.310 Inches Maximum Design Form: Plain Bore Type: Straight Bearings: Included Groove Quantity: 1 Counterbore Feature: Not Included Bearing Quantity: 1 Keying Facility: Not Included Split Hub Feature: Not Included Lightening Hole: Not Included Integral Cooling Vane: Not Included Groove Shape: U Bore Feature: Included Bearing Type: Ball Protruding Hub Characteristic: Plain Hub End Outside Diameter And Location: 0.759 Inches Minimum Both Ends And 0.769 Inches Maximum Both Ends Distance From Outside Flange/Rim To Hub End And Location: 0.064 Inches Nominal Both Ends Style Designator: Plain
