Country of Origin
United States
Shipping Weight
0.013 pounds
Manufacturer P/N
MS14102-16
Schedule B Code
8482.30.0040
Bore Diameter: 0.9995 Inches Minimum And 1.0000 Inches Maximum Outer Member Outside Diameter: 2.1245 Inches Minimum And 2.1250 Inches Maximum Outer Member Width: 1.0000 Inches Minimum And 1.0100 Inches Maximum Inner Member Width: 1.3730 Inches Minimum And 1.3750 Inches Maximum Static Radial Load Rating: 104000 Pounds Hardness Rating: 28.0 Rockwell C Minimum Outer Race Member And 37.0 Rockwell C Maximum Outer Race Member Hardness Rating: 55.0 Rockwell C Minimum Inner Member And 62.0 Rockwell C Maximum Inner Member Special Features: Passivation Optional Material: Plastic Polytetrafluoroethylene Race Liner Material: Steel Comp 440C Inner Member Material: Steel Comp 630 Outer Race Member Material Document And Classification: Ams5630 Assn Std Single Material Response Inner Member Material Document And Classification: Ams5643 Assn Std Single Material Response Outer Race Member Surface Treatment: Passivate Inner Member Style Designator: With Insert And/Or Liner
