Country of Origin
United States
Shipping Weight
0.5 pounds
Manufacturer P/N
MS21027-C231
Schedule B Code
8536.50.9065
Thread Class: 2B
Body Style: Bushing Mount
Overall Length: 0.572 Inches Maximum
Overall Height: 2.158 Inches Nominal
Overall Width: 0.556 Inches Maximum
Bushing Length: 0.469 Inches Nominal
Body Length: 0.572 Inches Maximum
Body Width: 0.556 Inches Maximum
Actuator Style: Round
Actuator Diameter: 0.430 Inches Maximum
Actuator Height: 0.983 Inches Nominal
Actuator Position-Action Relationship: Up Position Maintained And Down Position Maintained
Actuator Position-Locking Relationship: Up Position No Locking Action And Down Position Locked In
Maximum Voltage Rating In Volts: 115.0 Ac And 28.0 Dc
Mounting Surface To Terminal End Distance: 0.706 Inches Maximum
Inclosure Type: Hermetically Sealed
Mounting Method: Threaded Bushing
Features Provided: Actuator Seal
Thread Quantity Per Inch: 32
Nominal Thread Size: 0.469 Inches
Nonpile-Up Contact Arrangement: 2 Pole, Double Throw, Both Positions Maintained Single Switch Unit
Contact Load Current Rating At Maximum Rated Voltage: 5.000 Amperes Resistive Dc And 1.000 Amperes Inductive Dc And 2.000 Amperes Resistive Ac And 1.000 Amperes Inductive Ac
Precious Material And Location: Terminal Surfaces Gold
Test Data Document: 81349-Mil-S-8834 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Typedata On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
Thread Series Designator: Uns
Terminal Type And Quantity: 6 Tab, Solder Lug
Specification/Standard Data: 96906-Ms21027 Government Standard
