Country of Origin
United States
Shipping Weight
0.5 pounds
Schedule B Code
7616.99.5095
Thread Class: 2B
Thread Direction: Right-Hand
Locking Feature: Prevailing Torque All Metal Design
Mounting Hole Diameter: 0.098 Nominal Inches
Nut Style: Plate
Nut Length: 0.985 Inches Nominal
Nut Height: 1.100 Inches Nominal
Plate Thickness: 0.060 Inches Nominal
Plate Width: 0.396 Inches Nominal
Nut Mounting Provision: Straight Holes
Mounting Hole Arrangement Style: 2 Holes
Distance From Aperture Center To Mounting Hole Center: 0.344 Inches Nominal
Center To Center Distance Between Mounting Holes Along Length: 0.688 Inches Nominal
Thread Series: Unf
Thread Quantity Per Inch: 32
Nominal Thread Size: 0.190 Inches
Material: Aluminum Alloy 6061 Overall
Material Document And Classification: MIL-A-12545 Mil Spec Single Material Response Overall
