Amphenol NEXUS TJ-101 Black Plastic In-Line Molded Contact 4-Conductor Telephone Jack
Amphenol NEXUS TJ-101 Black Plastic In-Line Molded Contact 4-Conductor Telephone Jack
Our Part #:SGP156373
Manufacture Part #:TJ-101
Regular Price:
Our Price:
Our Price:
Sale Price:
$43.40
Price Per Each
SGP156373
Bulk Shop & Save
25 - 49
$42.78 ea.
50 - 74
$42.17 ea.
75 - 99
$41.59 ea.
100 +
$41.02 ea.
116
Each
configurable
false
TJ-101
Headset Jacks
Black
Plastic
2
ea
Each
117
INTERNATIONAL SHIPPING
SkyGeek welcomes international orders!
Please note: International orders are shipped from their respective locations, which may take an additional 7-10 days to process. We strive to consolidate items into one shipment to minimize duties and taxes. However, if items are located in different locations, separate shipments may be necessary.
This Jack Mates with Nexus Telephone Plug TP-101 with a Max Insertion Force of 10 Lbs & Withdrawl force of 6 Lbs Min to 10 Lbs Max
The Strain Relief Clamp is Intended for use with Cables Approx .275 Outside Dia.
The Solder Terminals each will accept two Stranded Conductors ff 404 Circular Mils (24 Gage, 41 Strands Of 40 Awg)
Each conductor is of one piece construction. There are no joints of any type between the contact area & the Solder Terminal.
The stay cord anchor will withstand a 50 Lb pull for at least 5 Min.
Materials:
Contacts-Breyllium Copper per Federal Spec QQ-C-533. Finish Nickel plater per Federal Spec QQ-N-290, Class 2, Type 6.
Body Insulation
Strain Relief Clamp; Stainless Steel per Federal Spec QQ-5-766, Class 4
Shell: Glass Filled Nylon, Black
Electrical:
Dielectric Strength: 500 Volts Rms Min between any pair of Contacts.
Insulation Resistance: 100 Megaohms Min between any pair of Contacts.
Contact Resistance: When Mated with Nexus TP-101 Telephone Plug and with a direct current of 100 Milliamperes at 5 Volts (Open Circuit Voltage)flowing through the Contacts, the Potential drop between each pair of contacts will not exceed .005 Volts.
