Country of Origin
United States
Shipping Weight
0.02 pounds
Manufacturer P/N
NAS8703-2
Schedule B Code
7318.15.9000
Thread Class: 3A Thread Direction: Right-Hand Thread Length: 0.298 Inches Minimum And 0.348 Inches Maximum Fastener Length: 0.433 Inches Minimum And 0.463 Inches Maximum Head Style: Flat Countersunk Head Diameter: 0.266 Inches Minimum And 0.303 Inches Maximum Grip Diameter: 0.1885 Inches Minimum And 0.1895 Inches Maximum Internal Drive Style: Cross Recess Type 1 Nominal Thread Diameter: 0.190 Inches Grip Length: 0.115 Inches Minimum And 0.135 Inches Maximum Thread Quantity Per Inch: 32 Minimum Tensile Strength: 160000 Pounds Per Square Inch Countersink Angle: 99.0 Degrees Minimum And 101.0 Degrees Maximum Surface Finish: 32.0 Microinches Threads Surface Finish: 32.0 Microinches Bearing Surface Of Head Surface Finish: 32.0 Microinches Grip Color: Green Threads Material: Iron Alloy 660 Overall Material Document And Classification: Ams 5731 Assn Std Single Material Response Overall Or Ams 5737 Assn Std Single Material Response Overall Surface Treatment: Cadmium Overall And Chromate Overall Surface Treatment Document And Classification: Qq-P-416,Ty 2,Cl 2 Fed Spec Single Treatment Response Overall Thread Series Designator: UNJC Specification/Standard Data: 80205-NAS8703 Professional/Industrial Association Standard
