Country of Origin
United States
Shipping Weight
0.001 pounds
Manufacturer P/N
MS17826-3
Schedule B Code
7318.16.0000
Ship Dimensions
2 x 2 x 0 inches
Thread Class: 3B Thread Direction: Right-Hand Locking Feature: Prevailing Torque With Nonmetallic Insert Nut Style: Slotted, Hexagon Nut Height: 0.173 Inches Minimum And 0.203 Inches Maximum Width Across Flats: 0.367 Inches Minimum And 0.376 Inches Maximum Temp Rating: 250.0 Deg Fahrenheit Nominal Thread Series: Unjf Thread Quantity Per Inch: 32 Nominal Thread Size: 0.190 Inches Bearing Surface Type: Washer Faced Material: Steel Nut Material: Plastic Polyamide Locking Insert Surface Treatment: Cadmium Overall Except Insert And Chromate Overall Except Insert Surface Treatment Document And Classification: Qq-P-416,Type 2,Class 2 Fed Spec Single Treatment Response Overall Except Insert
