Country of Origin
United States
Shipping Weight
0.03 pounds
Manufacturer P/N
MS17826-10
Schedule B Code
7318.16.0000
Ship Dimensions
1 x 1 x 1 inches
Thread Class: 3B
Thread Direction: Right-Hand
Locking Feature: Prevailing Torque With Nonmetallic Insert
Nut Style: Slotted, Hexagon
Nut Height: 0.298 Inches Minimum And 0.328 Inches Maximum
Width Across Flats: 0.928 Inches Minimum And 0.940 Inches Maximum
Temp Rating: 250.0 Deg Fahrenheit Nominal
Thread Series: Unjf
Thread Quantity Per Inch: 18
Nominal Thread Size: 0.625 Inches
Bearing Surface Type: Washer Faced
Special Features: Variable Pricing Item; Unit Of Issue Package Equal 50 Ea; To Order Unit Of Issue Each, Use Nsn 5310001113813
Material: Plastic Polyamide Locking Insert
Material: Steel Nut
Surface Treatment: Cadmium Overall Except Insert And Chromate Overall Except Insert
Surface Treatment Document And Classification: QQ-P-416, Type 2, Class 2 Fed Spec Single Treatment Response Overall Except Insert
