Country of Origin
United States
Shipping Weight
0.05 pounds
Schedule B Code
8536.50.9065
Body Style : Bushing Mount Bushing Length : 0.455 Inches Minimum And 0.485 Inches Maximum Body Length : 1.270 Inches Maximum Body Width : 0.635 Inches Maximum Body Height : 0.890 Inches Minimum And 0.930 Inches Maximum Actuator Style : Round Actuator Diameter : 0.237 Inches Minimum And 0.243 Inches Maximum Actuator Height : 0.665 Inches Minimum And 0.695 Inches Maximum Actuator Position-Action Relationship : Up Position Maintained And Down Position Maintained Maximum Voltage Rating In Volts : 115.0 Ac And 28.0 Dc Iii End Item Identification : Strategic Wepon Systems Inclosure Type : Fully Inclosed Mounting Method : Threaded Bushing Features Provided : Actuator Seal Thread Quantity Per Inch : 32 Nominal Thread Size : 0.469 Inches Nonpile-Up Contact Arrangement : 1 Pole, Single Throw, Both Positions Maintained Single Switch Unit Contact Load Current Rating At Maximum Rated Voltage : 15.000 Amperes Resistive Dc And 10.000 Amperes Inductive Dc And 4.000 Amperes Lamp Dc And 15.000 Amperes Resistive Ac And 7.000 Amperes Inductive Ac And 2.000 Amperes Lamp Ac Test Data Document : 81349-Mil-S-3950 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Typedata On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.). Thread Series Designator : Uns Terminal Type And Quantity : 3 Screw
