All Metal Blade DME/Transponder antenna designed and developed for Mach 2 military aircraft. Design is unique in the blade and mounting base are die-cast as one piece with no dielectric material in the airstream. Standard six-hole mounting configuration. See Order Options for available connectors.
| MODEL CI 100 DME / Transponder | |
| Electrical | |
| Frequency | 960 to 1220 MHz and 1030 to 1090 MHz |
| VSWR | 1.6:1 960 to 1220 MHz 1.4:1 1030 to 1090 MHz |
| Polarization | Vertical |
| Radiation Pattern | Equivalent of ? / 4 Stub |
| Impedance RF | 50 Ohms |
| Resistance DC | Open Circuit |
| Power RF | 2.5 KW Peak at 55,000 ft. |
| Mechanical | |
| Weight | 0.3 lb. Maximum |
| Height | 2.55 in. Maximum |
| Material | Die Cast A380 Aluminum Alloy |
| Finish | Polyurethane Enamel |
| Connector | BNC (female) |
| Environmental | |
| Temperature | -54ºC to +55ºC |
| Altitude | 45,000 ft. |
| Air Speed | Mach 2.5 |
| Federal Specifications | |
| RTCA Environmental | DO-138 |
| Environmental Category | AASXXXXXXXXX |
| FAA TSO | C66a, C74c |
| RTCA MOPS | DO-144, DO-189 |
| ORDER OPTIONS | |
| Connector | |
| BNC | CI 100 |
| TNC | CI 100-2 |
| C | CI 100-3 |
| HN | CI 100-4 |
| N | CI 100-5 |
| Color | |
| White | Standard |
| Gasket | |
| B10006 | |
