Country of Origin
United States
Shipping Weight
0.01 pounds
Schedule B Code
8536.10.0040
Body Style: Slotted Limiter
Terminal Material: Copper
Terminal Surface Treatment: Silver Plated
Overall Length: 3.188 Inches Nominal
Terminal Length: Any Acceptable
Center To Center Distance Between Mounting Facilities Parallel To Length: 2.438 Inches Nominal
Overall Height: 0.460 Inches Nominal
Overall Width: 0.875 Inches Nominal
Mounting Slot Width: 0.344 Inches Nominal
Case Material: Fiber
Continuous Current Rating In Amps: 100.000
Terminal Width: Any Acceptable
Terminal Thickness: Any Acceptable
Maximum Voltage Rating In Volts: 32.0 Ac And 32.0 Dc
Circuit Over-Current Interruption Type: Normal Instantaneous
Interruption Indicator Method: Visible Element
Short-Circuit/Interrupt Current Rating In Amps: 10000.0
Precious Material And Location: Terminal Surfaces Silver
Precious Material: Silver
