Military Specification D38999/20FA35SN Connector, Receptacle, Electrical

Our Part #: SGP161749
Manufacture Part #: D38999-20FA35SN
Our Price: $28.13 (Each)
world wide icon INTERNATIONAL SHIPPING

SkyGeek welcomes international orders!

Please note: such orders are funneled into our NY warehouse and may take an extra 7-10 days to process. The benefit to this: You get one package shipped which reduces added taxes and duties that may be incurred from multiple shipments.

  • Body Style: Straight Shape, External Coupling
  • Overall Length: 31.5 Millimeters Maximum
  • Overall Height: 23.8 Millimeters Nominal
  • Overall Width: 23.8 Millimeters Nominal
  • Center To Center Distance Between Mounting Facilities Parallel To Height: 18.26 Millimeters Nominal
  • Distance Between Centerlines Of Mounting Facilities Parallel To Body Width: 18.26 Millimeters Nominal
  • Distance From Mounting Shoulder To Front Face: 20.9 Millimeters Maximum
  • Mating End Quantity: 1
  • Contact Position Arrangement Style: 9-35 Single Mating End
  • Contact Removability: Removable Single Mating End Single Contact Grouping
  • Terminal Location: Back Single Mating End Single Contact Grouping
  • Terminal Type: Crimp Single Mating End Single Contact Grouping
  • Included Contact Quantity: 6 Single Mating End Single Contact Grouping
  • Included Contact Type: Round Socket Single Mating End Single Contact Grouping
  • Product Attributes

    Country of Origin
    United States
    Shipping Weight
    0.15 pounds
    ECCN
    EAR99
    Manufacturer P/N
    D38999/20FA35SN
    Schedule B Code
    8538.90.7080
    Pack Quantity
    1
    NSN
    5935-01-398-2507
    Military Standard
    MIL-C-38999/20
    Series
    D38999/20

    Other Part Numbers
