Country of Origin
United States
Shipping Weight
0.001 pounds
Manufacturer P/N
M24308/2-5F
Schedule B Code
8538.90.7080
Body Style: Straight Shape Overall Length: 2.620 Inches Minimum And 2.650 Inches Maximum Overall Height: 0.683 Inches Nominal Overall Width: 0.590 Inches Minimum And 0.620 Inches Maximum Environmental Protection: Moisture Proof And Salt Water Resistant And Vibration Proof Unthreaded Mounting Hole Diameter: 0.115 Inches Minimum And 0.125 Inches Maximum Distance Between Mounting Facility Centers: 2.059 Inches Minimum And 2.069 Inches Maximum Mating End Quantity: 1 Contact Position Arrangement Style: 50 Single Mating End Contact Removability: Removable Single Mating End Single Contact Grouping Shell Type: Solid Connector Locking Method: Friction Terminal Location: Back Single Mating End Single Contact Grouping Contact Material: Copper Alloy Single Mating End Single Contact Grouping Contact Surface Treatment: Gold Single Mating End Single Contact Grouping Insert Material: Plastic Diallyl Phthalate Single Mating End And Glass Fiber Single Mating End Or Plastic Polyester Single Mating End Contact Surface Treatment Document And Classification: Mil-G-45204,Ty 2,Gr C,Cl 1 Mil Spec Single Treatment Response Single Mating End Single Contact Grouping Terminal Type: Crimp Single Mating End Single Contact Grouping Shell Material: Metal Shell Surface Treatment: Cadmium Insert Material Document And Classification: Mil-M-14,Ty Sdg-F Mil Spec 1St Material Response Single Mating End And Mil-M-14,Ty Sdg-F Mil Spec 2Nd Material Response Single Mating End Or Mil-M-24519,Ty Gpt-30F Or Ty Get-30F Mil Spec 3Rd Material Response Single Mating End Included Contact Quantity: 50 Single Mating End Single Contact Grouping Included Contact Type: Round Socket Single Mating End Single Contact Grouping Precious Material And Location: Contact Surfaces Gold Precious Material And Weight: 0.050 Gold Grains, Troy Precious Material: Gold Test Data Document: 81349-Mil-Dtl-24308 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting Generaltype Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.). Specification/Standard Data: 81349-Mil-Dtl-24308/2 Government Specification
