Country of Origin
United States
Shipping Weight
0.003 pounds
Manufacturer P/N
HL19PB6-5
Schedule B Code
7318.23.0000
Thread Class: 3A
Thread Direction: Right-Hand
Fastener Length: 0.627 Inches Minimum And 0.647 Inches Maximum
Head Style: Flush Countersunk
Width Between Flats: 0.079 Inches Minimum And 0.081 Inches Maximum
Shank Diameter: 0.189 Inches Minimum And 0.190 Inches Maximum
Shank Style: Pin-Rivet, Straight, Threaded
Head Major Diameter: 0.297 Inches Minimum And 0.302 Inches Maximum
Grip Length: 0.317 Inches Maximum
Thread Quantity Per Inch: 32
Minimum Tensile Strength: 160000 Pounds Per Square Inch
Nominal Thread Size: 0.190 Inches
Shear Strength: 95000 Single Pounds Per Square Inch
Countersink Angle: 100.0 Degrees Nominal
Material: Steel Comp 4140 Overall Or Steel Comp 8740 Overall Or Steel Comp 4130 Overall
Material Document And Classification: Mil-S-5626 Mil Spec 1St Material Response Overall Or Mil-S-6049 Mil Spec 2Nd Material Response Overall Or Mil-S-6758 Mil Spec 3Rd Material Response Overall
Surface Treatment: Cadmium Overall
Surface Treatment Document And Classification: Qq-P-416,Ty 2,Cl 3 Fed Spec Single Treatment Response Overall
Thread Series Designator: UNJF
