Alternate PN#s
BAP0-0085-EC0402
Product Attributes
Country of Origin
United States
Shipping Weight
0.2 pounds
Manufacturer P/N
04-BAP0-0085-EC0402
Pack Quantity
1
Spring-Fast® Wire Protection Composite Grommet
Edging covers sharp edges and prevents wire
and cables from abrasion, preserving product
quality and reliability. It provides long-term
reliability under shock, vibration, salt spray, and
immersion, improving cosmetic appearance by
eliminating adhesive drips.
FEATURES:
Spring-Fast? Flexi Grommet?? Series has all the attributes of the "T" and "BT" Series, but has greater gripping strength for severe shock and vibration environments with 4-axis flexibility. Edging covers sharp edges and prevents wire
and cables from abrasion, preserving product
quality and reliability. It provides long-term
reliability under shock, vibration, salt spray, and
immersion, improving cosmetic appearance by
eliminating adhesive drips.
FEATURES:
- - Fastens to any 2-axis or 4-axis contour, such as:
- Oval Slot
- Lightening Hole
- Notched Slot
- Fabric Fastening
- U-Shape (Mouse Hole)
- Outside Right Angle
- Irregular Hole
- Inside Right
- ...AND MORE!!!
- Heat continuous to 185?F (85?C)
- Low Temperature to -40?F (-40? C)
- High Corrosion Resistance
- UL94 V-0 Flammability Rating
- Superior Dielectric Strength
- High Shock and Vibration Resistance to rms
G 41.7 - Continuous Edge Protection on Flanged Holes, 1/8" or greater Inside Radius and 1/4" or greater Outside Radius
10 CUT PIECES, 12.75", WHITE, 4 AXIS
| P/N Description | Sheet Thickness |
|---|---|
| BAP085C402 Cut Grommet | .020"-.030" (0.5-0.8mm) |
| BAP185C402 Cut Grommet | .029"-.045" (0.7-1.1mm) |
| BAP285C402 Cut Grommet | .044"-.056" (1.1-1.4mm) |
| BAP385C402 Cut Grommet | .055"-.069" (1.4-1.7mm) |
| BAP485C402 Cut Grommet | .069"-.090" (1.7-2.3mm) |
| BAP585C402 Cut Grommet | .089"-.114" (2.3-2.9mm) |
| BAP685C402 Cut Grommet | .113"-.130" (2.9-3.3mm) |
