Country of Origin
United States
Shipping Weight
0.05 pounds
Manufacturer P/N
622EN1-6
Schedule B Code
8536.50.9065
Thread Class: 2A Body Style: Bushing Mounted Body Diameter: 0.720 Inches Maximum Bushing Length: 0.595 Inches Minimum And 0.655 Inches Maximum Body Length: 1.000 Inches Maximum Actuator Style: Roller Plunger Actuator Free Position Height: 1.295 Inches Nominal Actuator Roller Diameter: 0.375 Inches Nominal Actuator Roller Width: 0.120 Inches Nominal Maximum Voltage Rating In Volts: 28.0 Dc End Item Identification: Mrap Inclosure Type: Fully Inclosed Mounting Method: Threaded Bushing Features Provided: Actuator Seal Thread Quantity Per Inch: 32 Nominal Thread Size: 0.469 Inches Nonpile-Up Contact Arrangement: 2 Pole, Double Throw, One Position Momentary Single Switch Unit Switch Release Force: 64.0 Ounces Minimum Switch Actuating Force: 96.0 Ounces Minimum And 192.0 Ounces Maximum Actuator Movement: 0.040 Pretravel Inches Maximum And 0.125 Overtravel Inches Minimum And 0.020 Differential Inches Maximum Contact Load Current Rating At Maximum Rated Voltage: 7.000 Amperes Resistive Dc And 4.000 Amperes Inductive Dc And 4.000 Amperes Motor Dc Test Data Document: 81349-Mils8805 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Typedata On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.). Thread Series Designator: Uns Terminal Type And Quantity: 6 Wire Lead Specification/Standard Data: 81349-Mils8805/43 Government Specification
