Country of Origin
United States
Shipping Weight
0.05 pounds
Manufacturer P/N
311SM3-T
Schedule B Code
8536.50.9065
Body Style : Hole Mounted
Center To Center Distance Between Mounting Facilities Parallel To Length : 0.375 Inches Nominal
Body Length : 0.781 Inches Nominal
Body Width : 0.250 Inches Nominal
Body Height : 0.356 Inches Nominal
Unthreaded Mounting Hole Diameter : 0.087 Inches Nominal
Actuator Length : 2.343 Inches Nominal
Actuator Style : Leaf
Actuator Width : 0.140 Inches Nominal
Actuator Free Position Height : 0.590 Inches Nominal
Maximum Voltage Rating In Volts : 250.0 Ac And 30.0 Dc
Inclosure Type : Fully Inclosed
Mounting Method : Unthreaded Hole
Nonpile-Up Contact Arrangement : 1 Pole, Double Throw, Both Positions Maintained Single Switch Unit
Switch Release Force : 2.0 Grams Minimum
Switch Actuating Force : 15.0 Grams Maximum
Actuator Movement : 0.310 Pretravel Inches Maximum And 0.034 Overtravel Inches Minimum And 0.077 Differential Inches Maximum
Contact Load Current Rating At Maximum Rated Voltage : 5.000 Amperes Resistive Dc And 3.000 Amperes Inductive Dc And 5.000 Amperes Resistive Ac And 3.000 Amperes Inductive Ac
Terminal Type And Quantity : 3 Turret
